BAM continues distribution of the certified fluorescence emission standard “Calibration Kit” - BAM F001b – BAM F005b NEW: BAM-FCalKit
The certified fluorescence emission standard BAM FCalKit “Calibration Kit” contains BAM F001b – BAM F005b as a set and is a tool for the calibration and performance testing of fluorescence instruments. It enables the traceable determination of the wavelength-dependent relative spectral responsivity s(λ) of the emission channel/detection system of fluorescence instruments under conditions used for routine fluorescence measurements, using the data measured of the CRM BAM-FCalKit by the user and the BAM evaluation software LinkCorrWinV1.3.
The CRM BAM FCalKit can also be used for:
• Determination of spectrally corrected, instrument-independent fluorescence emission spectra.
• Determination of the long-term stability of the emission detection system of fluorescence instruments.
• Instrument Performance Validation (IPV) of fluorescence instruments.The CRM BAM FCalKit is available as a set of 5 broadband emitting dyes, that are spectrally adapted to each other. For the application as spectral fluorescence standards the dyes provided as solid samples, must be dissolved in absolute ethanol. The BAM evaluation software LinkCorrWinV1.3 is accessible as a password protected download after purchase. The SOP for the application of the CRM BAM FCalKit, developed and validated by BAM, and the certificates of the 5 dyes (spectrally corrected, normalized emission spectra and their wavelength-dependent measurement uncertainties) are included in LinkCorrWinV1.3.
The previous distribution was carried out by Sigma Aldrich, product number 75255.
Info: Division Biophotonics, B.Sc. Maria Richter
2024/02/08
-
New Micoplastic Reference Material BAM-P206 „Polyethylene terephtalat (PET)“
The reference material BAM-P206 is a Polyethylene terephthalate (PET) for analyzing microplastics in environmental samples. It represents a close to reality reference material with characteristic value particle size, that is suitable for validation of sampling, sample preparation and detection of microplastics. At the same time, it can be used for evaluation of effects in the field of ecotoxicology, human toxicology, contaminant transport and agglomeration behavior related to microplastics. The particles are top-down produced by centrifugal mill, have an irregular shape and, as is typical in nature, exhibit a range of particle sizes and aging status. The reference material BAM-P206 is available as a powder in glass bottles with 1 g filling.
2024/01/30
-
New certified reference material BAM-M316a AlSi12(Fe)
In the new certified reference material BAM-M316a AlSi12(Fe) which replaces the sold out CRM ERM-EB316, mass fractions of the elements Si, Fe, Cu, Mn, Mg, Ni, Cr, Ga, Zn, Ti, Ag, Be, Bi, Ca, Cd, Pb, Sb, Sn, Sr, V and Zr have been certified. Certification was done in an international certification round robin in cooperation with the working group “Aluminium” of the committee of chemists of GDMB (Gesellschaft der Metallurgen und Bergleute e.V.). In total ten laboratories from industry and research participated in the certification interlaboratory comparison using different analytical methods for material characterisation.
The new certified reference material BAM-M316a is available in form of discs (30 mm height, ca. 50 mm diameter) for calibration and quality control in spark emission and X-ray fluorescence spectrometry.Info: Inorganic Reference Materials, Dr. Sebastian Recknagel,
2023/12/20
-
New certified reference material BAM-S006 Multielement-glass
The new certified reference material BAM-S006, a multi-element glass for X-ray fluorescence analysis, was completed. It complements the glass CRM BAM-S005c. The multi-element glass was characterised in an international interlaboratory comparison in cooperation with the International Commission on Glass (ICG) and the Deutsche Glastechnische Gesellschaft e.V. (DGG). The mass fractions of the elements Al, Ca, Mg, Na, K, Fe, Cr, Mn, Si, As, Ba, Cd, Co, Ni, P, Pb, S, Sb, and Ti were certified. A total of 18 laboratories from industry and research participated in the certification interlaboratory comparison, using different analytical methods to characterize the material.
The CRM is available in disc form (height: approx. 4 mm, diameter: approx. 38 mm) as well as in form of cullet (50 g) and is intended for calibration and quality control in X-ray fluorescence and wet chemical analysis.Info: Inorganic Reference Materials, Dr. Sebastian Recknagel
2023/11/13
-
New: CRM BAM-U117 - total cyanide in soil
The new reference material BAM-U117 is a sandy soil that was certified for its content of total cyanide on the basis of the International Standards DIN ISO 11262:2012 and DIN EN ISO 17380:2013. It replaces CRM BAM-U116.
The CRM is available as a powder with particle sizes below 125 µm and is supplied in 100 mL amber glass bottles containing (77 ± 1) g. It is intended for the verification of analytical results obtained when applying the above mentioned standard procedures. As any reference material, it can also be used for routine performance checks (quality control charts) or validation studies.CRM BAM-U117 | Report | Info: Division Inorganic Reference Materials, Dr. Sebastian Recknagel
2023/11/13
-
New certified reference material BAM-M325 AlSi7MgSr
In the new certified reference material BAM-M325 AlSi7MgSr, an alloy type which have not been certified by BAM before, mass fractions of the elements Si, Fe, Cu, Mn, Mg, Cr, Ga, Zn, Ti, Ca, Cd, Li, Ni, Pb, Sb, Sn, Sr, V and Zr have been certified. Certification was done in an international certification round robin in cooperation with the working group “Aluminium” of the committee of chemists of GDMB (Gesellschaft der Metallurgen und Bergleute e.V.). In total ten laboratories from industry and research participated in the certification interlaboratory comparison using different analytical methods for material characterisation.
The new certified reference material BAM-M325 is available in form of discs (30 mm height, ca. 50 mm diameter) for calibration and quality control in spark emission and X-ray fluorescence spectrometry.Info: Inorganic Reference Materials, Dr. Sebastian Recknagel,
2023/11/13
-
New: Certified Reference Material BAM-A001 „Polycyclic Aromatic Hydrocarbons in Olive Oil“
BAM-A001 is a certified reference material (CRM) for the determination of polycyclic aromatic hydrocarbons (PAH) in olive oil. With its relevant PAH contents, BAM-A001 supports the monitoring of the applicable PAH maximum levels according to Commission Regulation (EC) 2023/915.
The development and certification of BAM-A001 was based on ISO Guide 35. For the analytical determination independent sample preparation methods as well as gas chromatography-mass spectrometry (GC-MS) with stable-isotope dilution were used.
PAHs are among the priority organic pollutants in environmental matrices, consumer products, and food. The latter group is at risk for PAH contamination from several factors, including environmental contamination, processing operations, and migration from contact materials.
BAM-A001 is available from BAM at a price of 221,- € plus VAT in an amber glass vial (outer packaging: centrifuge tube) with 14 mL content.
Info: Organic Trace and Food Analysis, Dr. Matthias Koch
2023/10/19
-
New: BAM-S014 Li-NMC 111 Cathode material
BAM has recently issued the new certified reference material BAM-S014, a Li-NMC 111 cathode material with certified contents for the elements Li, Ni, Mn, Co, O, Al, C, Cr, S, Na und Fe and informative values for the mass fractions of P as well as particle size distribution and specific surface area. Certification was carried out within the framework of an inter-laboratory comparison involving 16 expert laboratories in co-operation with the working group “Special Materials” of the committee of chemists of GDMB (Gesellschaft der Metallurgen und Bergleute e.V.). BAM-S014 is intended for the calibration of analytical instruments and to validate or verify analytical methods suitable for the analysis of niobium carbide.
The powdered material is available in glass bottles, containing 25 g, each.
BAM-S014 report
Info: Inorganic Reference Materials, Dr. Sebastian Recknagel
2023/03/28
-
New: ECRM D 286-2 - high alloy steel (1.4305)
In the newly certified reference material EZRM D 286-2, a high alloy steel, the mass fractions of the elements C, Si, Mn, P, S, Cr, Mo, Ni, Cu, Co, N, Sn, and V are certified. The reference material was certified in an international certification ring test with renowned national and international laboratories in cooperation with the EURONORM CRM producers group. The CRM is available in the form of chips (100 g). It replaces the ECRM 286-1, which is not available any more.
ECRM D 286-2 | Info: Inorganic Reference Materials, Dr. Sebastian Recknagel
2023/03/28
-
New: BAM-S013 Niobium carbide powder
BAM has recently issued the new certified reference material BAM-S013, a niobium carbide powder with certified contents for the elements cabon and oxygen and informative values for the mass fractions of C(Free), N, S, and H. Certification took place within the framework of an inter-laboratory comparison involving 15 expert laboratories in co-operation with the working group “Special Materials” of the committee of chemists of GDMB (Gesellschaft der Metallurgen und Bergleute e.V.). BAM-S013 is intended for the calibration of analytical instruments and to validate or verify analytical methods suitable for the analysis of niobium carbide.
The powdered material is available in glass bottles, containing 60 g, each.
BAM-S013 report
Info: Inorganic Reference Materials, Dr. Sebastian Recknagel
2022/12/28
-
New: BAM-U024 and BAM-U025: AOX in sludge or soil
The certified reference materials BAM-U024 and BAM-U025 are used to verify the direct determination of adsorbed organically bound halogens (AOX: chlorine, bromine and iodine) in sludges and soils, respectively, according to DIN 38414-18 (2019). They replace the former soil reference materials ERM-CC010, ERM-CC011 and ERM-CC012. The new reference materials were characterised in an interlaboratory comparison with ten experienced laboratories. The two CRMs are available in glass bottles with a content of 5.4 g each.
CRM BAM-U024 | CRM BAM-U025 | report | Info: Division 1.7 Organic Trace and Food Analysis, Dr. Roland Becker
-
New reference materials: BAM-U200 and BAM-U201 Sewage sludge asches
Sewage sludge ashes have so far been "recycled" as backfill material, additive for cement, ceramics and bricks or as material for landfill construction, or they are deposited as waste above or below ground. In terms of sustainable resource management, however, sewage sludge ashes also represent an interesting, potentially sustainable source of phosphate. Since phosphate deposits are limited, the potential recovery of phosphate from sewage sludge ashes and its processing into fertiliser is of particular importance. In order to prove compliance with the limit values for the respective recovery or disposal option according to the legal regulations, the sewage sludge ashes must be analysed for their contents prior to the respective recovery.
The two reference materials are an iron rich (BAM-U200) and an aluminium rich sewage sludge ash (BAM-U201). Reference values were determined for the mass fractions of the elements Al, As, Ca, Cd, Cr, Cu, Fe, K, Mg, Na, Ni, P, Pb, Sn, and Zn. In addition to the total contents, the contents of these elements extractable with aqua regia were also determined. The determination of element contents after extraction with aqua regia as a convention method plays an increasingly important role in the daily practice of testing laboratories in the assessment of environmentally relevant pollutant loads and is prescribed in numerous national and international regulations.BAM-U200 report
BAM-U201 reportInfo: Division 1.4 Process Analytical Technology, Dr. Markus Ostermann
2022/10/31
-
New: certified reference material Stahl-H2 for hydrogen-determination
The new certified reference material CRM Stahl-H2, a high-alloy steel, was certified in an international certification interlaboratory comparison with participating laboratories from the steel industry, equipment manufacturers and research institutes. Certified is the hydrogen mass fraction of 1.26 mg/kg. The CRM is intended for the calibration of analyzers for the determination of hydrogen content as well as for analysis control.
The CRM is available in the form of pins with a mass of 1 g each and a diameter of 6 mm, packed in bottles containing 100 pins.
CRM Stahl-H2 certificate
Info: Inorganic Reference Materials, Dr. Sebastian Recknagel
2022/08/25
-
New: BAM-N008 – silver nanoparticles
The new reference material BAM-N008 is an aqueous dispersion of silver nanoparticles.
The intended purpose of BAM-N008 is the verification of analytical results obtained for determination of diameter, size distribution width, number density and mass concentration of nanoparticles in dispersion. Preferred use is quality control of particle size analysis with the SAXS method according to ISO 17867.
Diameter (5.8 nm) and number density of the particles (3.7 µmol/l) are provided as metrologically traceable values. Particle size distribution width (1.33 nm) and particle concentration (3.0 g/l) are provided in not traceable form.2022/08/25
-
CRM BAM-S004 available again
CRM BAM-S004 "Glass Containing Hexavalent Chromium", which was temporarily unavailable, is now available again.
BAM-S004 | Info: Inorganic Reference Materials, Dr. Sebastian Recknagel
2022/08/25
-
New reference materials: BAM-U030 Pentachlorophenol (PCP) in Wood BAM-U130 Trace Elements in Wood
The efficient recycling of waste wood, which accumulates in large quantities in numerous sectors, is becoming increasingly important in terms of sustainable resource management. Since wood was often impregnated with substances that are now banned in the past, the use of waste wood (recycling or incineration) is regulated in several European countries. Reliable analytical data are thus required for a decision regarding the further use of waste wood, which - due to their great economic and ecological impact - must be backed up by suitable quality control.
The two new certified reference materials BAM-U030 and BAM-U130 replace the first material ERM-CD100, which has been sold out in the meantime and in which the mass fractions of arsenic, cadmium, chromium, copper, lead, mercury and pentachlorophenol (PCP) were certified. The starting materials were different types of wood, which were crushed by cryogenic grinding and then prepared to obtain contents of heavy metals (BAM-U130) or PCP (BAM-U030) in the range of the limit values of the Waste Wood Ordinance.
The two CRMs can be used within the framework of internal laboratory quality assurance to verify (determine the trueness and precision) the analytical results obtained with known test methods and to validate modified or new methods.BAM-U030 report
BAM-U130 reportInfo: Division 1.6 Inorganic Reference Materials, Dr. Sebastian Recknagel
Division 1.7 Organic Trace and Food Analysis, Dr. Roland Becker2022/07/07
-
New certified reference material BAM-M323 AlFe1
In the new certified reference material BAM-M323 AlFe1, an alloy type which have not been certified by BAM before, mass fractions of the elements Si, Fe, Cu, Mn, Mg, Cr, Ga, Zn, Ti, Be, Bi, Ca, Cd, Co, Hg, Li, Na, Ni, Pb, Sb, Sn, V and Zr have been certified. Certification was done in an international certification round robin in cooperation with the working group “Aluminium” of the committee of chemists of GDMB (Gesellschaft der Metallurgen und Bergleute e.V.). In total eight laboratories from industry and research participated in the certification interlaboratory comparison using different analytical methods for material characterisation.
The new certified reference material BAM-M323 is available in form of discs (30 mm height, ca. 65 mm diameter) for calibration and quality control in spark emission and X-ray fluorescence spectrometry.Info: Inorganic Reference Materials, Dr. Sebastian Recknagel,
2022/05/30
-
New certified reference material BAM-M324 AlMn1Mg1Cu
In the new certified reference material BAM-M324 AlMn1Mg1Cu, an alloy type which have not been certified by BAM before, mass fractions of the elements Si, Fe, Cu, Mn, Mg, Cr, Ga, Zn, Ti, B, Be, Bi, Ca, Cd, Co, Hg, Li, Ni, Pb, Sb, Sn, Sr, V and Zr have been certified. Certification was done in an international certification round robin in cooperation with the working group “Aluminium” of the committee of chemists of GDMB (Gesellschaft der Metallurgen und Bergleute e.V.). In total nine laboratories from industry and research participated in the certification interlaboratory comparison using different analytical methods for material characterisation.
The new certified reference material BAM-M324 is available in form of discs (30 mm height, ca. 65 mm diameter) for calibration and quality control in spark emission and X-ray fluorescence spectrometry.Info: Inorganic Reference Materials, Dr. Sebastian Recknagel,
2022/05/30
-
New: BAM-K008a – Diesel oil, additive free and without FAME
The new reference material BAM-K008a is an additive free diesel oil without FAME (fatty acid methyl esters), whose mass fraction of the boiling range C10 - C40 (n-decane to n-tetracontane) has been certified. BAM-K008a is intended to be used as a type A mineral oil of a calibration standard for the gas chromatographic determination of mineral oil hydrocarbons in water, soil and waste according to the analytical standard procedures ISO 9377-2, ISO 16703 and EN 14039. BAM-K008a replaces the sold out calibration standard BAM-K008. The reference material is available in glass vials with at least 2.0 mL content.
Info: Organic Trace and Food Analysis, Dr. Matthias Koch
2022/05/03
-
New: BAM-K009a – Lubricating oil, additive free
The new reference material BAM-K009a is an additive free lubricating oil, whose mass fraction of the boiling range C10 - C40 (n-decane to n-tetracontane) has been certified. BAM-K009a is intended to be used as a type B mineral oil of a calibration standard for the gas chromatographic determination of mineral oil hydrocarbons in water, soil and waste according to the analytical standard procedures ISO 9377-2, ISO 16703 and EN 14039. BAM-K009a replaces the sold out calibration standard BAM-K009. The reference material is available in glass vials with at least 2.0 mL content.
Info: Organic Trace and Food Analysis, Dr. Matthias Koch
2022/05/03
-
New certified reference material BAM-M384c pure Copper
In the new certified reference material BAM-M384c pure copper, which replaces the exhausted CRM BAM-M384, mass fractions of the elements Ag, Al, As, Bi, Cd, Co, Fe, Mg, Mn, Ni, P, Pb, S, Sb, Se, Sn, Te, Ti, Zn, and Zr have been certified. Certification was done in an international certification round robin in cooperation with the working group “Copper” of the committee of chemists of GDMB (Gesellschaft der Metallurgen und Bergleute e.V.). In total 13 laboratories from industry and research participated in the certification interlaboratory comparison using different analytical methods for material characterisation.
The new certified reference material BAM-M384c is available in form of discs (30 mm height, ca. 40 mm diameter) for calibration and quality control in spark emission spectrometry.Info: Inorganic Reference Materials, Dr. Sebastian Recknagel,
2022/04/12
-
New certified reference material BAM-M504b automobile catalyst
The use of automobile catalysts is necessary to comply with international limits for exhaust emissions of cars. The catalysts normally are made of a ceramic hollow piece plated with the platinum group elements platinum, palladium and rhodium as active components. The precious metals contained in the catalysts represent a considerable value, therefore high demands on precision and accuracy of the analysis are following. For that reason a few years ago BAM certified the reference material ERM®-EB504 and later ERM®-EB504a. This CRM is no longer available. Aim of the certification of the reference material BAM-M504b was to certify a suitable subsequent material with certified mass fractions of the precious metals Pt, Pd und Rh with small uncertainties. The CRM is produced using a used cordierite based car catalyst with mass fractions of (1159 ± 8) mg/kg of platinum, (1128 ± 9) mg/kg of palladium and (314,2 ± 2,6) mg/kg of rhodium. The material is available in form of powder (particle size < 0,1 mm) in bottles containing 200 g. It is intended as a tool for laboratories for development, validation and quality control of analytical methods for the determination of platinum group elements in automobile catalysts.
Info: Inorganic Reference Materials, Dr. Sebastian Recknagel
2022/03/24
-
New certified reference material BAM-M383d pure Copper
In the new certified reference material BAM-M383d pure copper, which replaces the exhausted CRM BAM-M383, mass fractions of the elements Ag, Al, As, Bi, Cd, Co, Cr, Fe, Mg, Mn, Ni, P, Pb, S, Sb, Sn, Te, Ti, Zr, and Zn have been certified. Certification was done in an international certification round robin in cooperation with the working group “Copper” of the committee of chemists of GDMB (Gesellschaft der Metallurgen und Bergleute e.V.). In total 11 laboratories from industry and research participated in the certification interlaboratory comparison using different analytical methods for material characterisation.
The new certified reference material BAM-M383d is available in form of discs (30 mm height, ca. 40 mm diameter) for calibration and quality control in spark emission spectrometry.Info: Inorganic Reference Materials, Dr. Sebastian Recknagel,
2021/10/04
-
New certified reference material BAM-M322 AlMn1Cu
In the new certified reference material BAM-M322 AlMn1Cu, an alloy type which have not been certified by BAM before, mass fractions of the elements Si, Fe, Cu, Mn, Mg, Cr, Ni, Zn, Ti, Be, Bi, Ca, Cd, Co, Ga, Li, Na, Pb Sn, V, and Zr have been certified. Certification was done in an international certification round robin in cooperation with the working group “Aluminium” of the committee of chemists of GDMB (Gesellschaft der Metallurgen und Bergleute e.V.). In total 10 laboratories from industry and research participated in the certification interlaboratory comparison using different analytical methods for material characterisation.
The new certified reference material BAM-M322 is available in form of discs (30 mm height, ca. 65 mm diameter) for calibration and quality control in spark emission and X-ray fluorescence spectrometry.Info: Inorganic Reference Materials, Dr. Sebastian Recknagel,
2021/09/13
-
New certified reference material BAM-P114 porous titanium dioxide for the determination of the specific surface area (BET)
The new reference material BAM-P114 is a porous titanium dioxide in a mixture of the modification anatase and rutile and certified for gas adsorption for the determination of the specific surface area (BET) based on the International Standard ISO 9277:2010. With its specific surface area of 24.48 m²/g, it complements BAM's range of porous reference materials.
The certification took place as part of an international round robin test. The reference material is supplied as granules in 30 mL glass bottles of 18 g each. It can be used for validation as well as for routine internal quality assurance.BAM-P114 | reportInfo: Structure Analysis, Carsten Prinz
2021/09/13
-
New: certified reference material D 267-1 for oxygen- and nitrogen-determination
The new certified reference material ZRM D 267-1, a high-alloy steel, was certified in an international certification interlaboratory comparison with participating laboratories from the European steel industry, equipment manufacturers and research institutes. It is issued by the German Working Group for Certified Reference Materials Iron and Steel, consisting of BAM, the Steel Institute VDEh and the Max Planck Institute for Iron Research. Certified is the oxygen mass fraction of 0.00096 % and the nitrogen mass fraction of 0.0266 %. The CRM is intended for the calibration of analyzers for the determination of oxygen and nitrogen content as well as for analysis control.
The CRM is available in the form of pins with a mass of 1 g each and a diameter of 4 mm, packed in bottles containing 100 pins.
ECRM D267-1 certificate
Info: Inorganic Reference Materials, Dr. Sebastian Recknagel
